Product Overview
The UV Laser Marking Machine is designed for ultra-fine and high-precision marking applications on delicate materials.
Its advanced UV laser technology minimizes heat impact, ensuring clean, detailed, and damage-free marking results.
Ideal for electronics, plastics, medical devices, and precision components, the machine delivers stable performance and exceptional marking quality.
Key Features
Ultra-Fine Marking
Delivers highly detailed and accurate markings on delicate and sensitive materials.
Low Heat Impact
UV laser technology reduces thermal damage and ensures clean surface finishing.
24/7 Service Support
Dedicated local and online support for smooth and uninterrupted operations.
Free Installation
Complete installation and operator training provided at client premises.
Technical Specification
| Model |
PULSE |
| Laser Type |
UV Laser |
| Laser Output Power |
3W / 5W / 10W |
| Marking Area |
50 × 50 mm, 100 × 100 mm, 170 × 170 mm |
| Marking Speed |
14000 mm/Second |
| Min. Character Size |
0.2 mm, 0.5 mm |
| Min. Line Width |
50 μm – 90 μm |
| Wavelength |
1064 nm |
| Beam Quality M2 |
< 1.6 |
| Power Stability (8h) |
< ±1% rms |
| Pulse Repetition Frequency |
1.6 kHz – 1000 kHz |
| Marking Depth |
≤ 0.016″ |
| Repetition Accuracy |
±0.0001″ |
| Power Consumption |
500W |
| Indication Light |
Red Light Wavelength = 650 nm |
| Cooling Mode |
Water Cooling |
| Running Temperature |
15℃ – 35℃ |
| Electrical Source Requirement |
110 – 220V / 50Hz (60Hz) / 4A |
| Dimensions (L × W × H) |
650 × 700 × 1600 mm |
| Weight |
135 KG |
