Product Overview
The Fly Laser Marking Machine is designed for high-speed and continuous marking applications in industrial production lines.
Equipped with advanced fiber laser technology and a high-speed controller, it delivers precise, permanent, and consistent markings on moving products.
Its reliable performance and automation-ready design make it ideal for large-scale manufacturing environments.
Key Features
Continuous Inline Marking
Designed for high-speed production lines with accurate marking on moving products.
High-Speed Controller
Advanced marking controller ensures stable and efficient industrial performance.
24/7 Service Support
Dedicated local and online support for uninterrupted machine operation.
Free Installation
Complete installation and operator training provided at client premises.
Technical Specification
| Model |
FLY MARK |
| Laser Output Power |
30W / 50W / 70W / 100W |
| Controller |
High Speed Marking Controller |
| Marking Area |
100 × 100 mm, 170 × 170 mm |
| Marking Speed |
8000 mm/Second |
| Min. Character Size |
0.2 mm, 0.5 mm |
| Min. Line Width |
50 μm – 90 μm |
| Wavelength |
1064 nm |
| Beam Quality M2 |
< 1.6 |
| Power Stability (8h) |
< ±1% rms |
| Pulse Repetition Frequency |
1.6 kHz – 1000 kHz |
| Marking Depth |
≤ 0.016″ |
| Repetition Accuracy |
±0.0001″ |
| Power Consumption |
1000W |
| Indication Light |
Red Light Wavelength = 650 nm |
| Cooling Mode |
Air Cooling – Panel AC |
| Running Temperature |
15℃ – 35℃ |
| Electrical Source Requirement |
110 – 220V / 50Hz (60Hz) / 4A |
| Dimensions (L × W × H) |
650 × 700 × 1600 mm |
| Weight |
165 KG |
