Product Overview
The 4 Axis Fiber Laser Welding Machine is designed for complex and high-precision welding applications across various industries.
Its advanced multi-axis control system enables accurate movement and consistent welding quality for intricate components.
Powered by fiber laser technology, the machine delivers efficient performance, minimal heat distortion, and reliable industrial productivity.
Key Features
4 Axis Control System
Advanced multi-axis movement ensures accurate and flexible welding operations.
High Precision Welding
Delivers strong, clean, and consistent welds with minimal heat impact.
24/7 Service Support
Reliable local and online technical support for uninterrupted machine operation.
Free Installation
Complete installation and operator training provided at client premises.
Technical Specification
| Model |
WeldPro |
| Laser Output Power |
1000W / 1500W / 2000W / 3000W |
| Electrical Requirement |
220V |
| Machine Power Consumption |
16KW |
| X Axis |
500 mm |
| Y Axis |
500 mm |
| Z Axis |
500 mm |
| XY Axis Speed |
60 m/min |
| Positioning Accuracy |
0.08 mm |
| Product Fixture |
Optional |
| Laser Material |
Continuous Pulse |
| Laser Wavelength |
1070 nm |
| Power Adjustment Range |
1 – 100% |
| Aiming and Positioning |
Red Light |
| Pulse Width |
Continuous Light |
| Repeating Position Precision |
±0.01 mm |
| Power Stability |
±1% |
| Operating Platform |
PC |
| Cooling Method |
Water Cooling |
| Machine Dimension |
1000 × 1450 × 2300 mm |
| Water Chiller Dimension |
750 × 510 × 1000 mm |
