Product Overview
The Sheet Metal Laser Cutting Machine is designed for high-speed and precision cutting of various metal sheets.
Built with a heavy-duty structure, it ensures stability, minimal vibration, and accurate cutting results.
With advanced fiber laser technology, the machine delivers excellent performance, energy efficiency, and long-term reliability, making it ideal for modern industrial applications.
Key Features
Heavy Body Structure
Ensures stability and reduces vibration for precise and accurate cutting performance.
2 Years Warranty
Includes on-site support with free replacement parts and repair services.
24/7 Service Support
Continuous local and online support to ensure smooth and uninterrupted operations.
Free Installation
Complete installation and operator training provided at your location.
Technical Specification
| Laser Type |
Fiber Laser |
| Laser Wavelength |
1070 – 1080 nm |
| Laser Source Brand |
Raycus / Max / IPG / JPT |
| Cutting Head |
Raytools / BOSCHU / WSX |
| Controller System |
CypCUT / Raytools / Beckhoff |
| Pulse Frequency |
1 – 20000 Hz |
| Repeated Accuracy (X/Y) |
±0.05 mm |
| Servo System |
Delta / Panasonic / Flexem / Yasakawa (EtherCAT) |
| Rack and Pinion |
YYC – Taiwan |
| Rail Guide |
PMI / Hiwin |
| Cooling Type |
Water Cooling |
| Chiller |
S&A / HexaCool / Hanli |
| Operating Temperature |
0°C – 40°C |
| Model |
M-3015 iNTELLICUT |
M-2040 iNTELLICUT |
M-2565 iNTELLICUT |
| X Axis |
1500 mm |
2000 mm |
2500 mm |
| Y Axis |
3000 mm |
4000 mm |
6500 mm |
| Z Axis |
150 mm |
150 mm |
150 mm |
| Running Speed |
100 m/min |
100 m/min |
100 m/min |
| Weight of Base Machine |
3000 Kg |
3800 Kg |
5800 Kg |
| Dimensions |
4500 × 3000 × 1600 mm |
5500 × 3200 × 1600 mm |
8100 × 3250 × 1600 mm |
| Maximum Workpiece Weight |
900 Kg |
1500 Kg |
2100 Kg |
| Laser Power – 1500W |
| Mild Steel (mm) |
10 |
10 |
10 |
| Stainless Steel (mm) |
6 |
6 |
6 |
| Laser Power – 3000W |
| Mild Steel (mm) |
16 |
16 |
16 |
| Stainless Steel (mm) |
10 |
10 |
10 |
| Aluminium Alloy (mm)** |
6 |
6 |
6 |
| Brass (mm)** |
5 |
5 |
5 |
| Copper (mm)** |
3 |
3 |
3 |
| Laser Power – 6000W |
| Mild Steel (mm) |
25 |
25 |
25 |
| Stainless Steel (mm) |
18 |
18 |
18 |
| Aluminium Alloy (mm)** |
15 |
15 |
15 |
| Brass (mm)** |
10 |
10 |
10 |
| Copper (mm)** |
6 |
6 |
6 |
| Laser Power – 12000W |
| Mild Steel (mm) |
40 |
40 |
40 |
| Stainless Steel (mm) |
35 |
35 |
35 |
| Aluminium Alloy (mm)** |
25 |
25 |
25 |
| Brass (mm)** |
12 |
12 |
12 |
| Copper (mm)** |
10 |
10 |
10 |
| Max Acceleration |
1.2G |
1.2G |
1.2G |
| Supported Formats |
.DXF / .DWG |
.DXF / .DWG |
.DXF / .DWG |
| Power Supply |
380V / 50Hz / Three Phase |
380V / 50Hz / Three Phase |
380V / 50Hz / Three Phase |
