Product Overview
The Table Top Laser Marking Machine is a compact and efficient solution designed for precise and permanent marking applications.
Its space-saving tabletop design makes it ideal for workshops, production units, and industrial environments with limited space.
Powered by advanced fiber laser technology, the machine delivers fast, accurate, and high-quality marking performance with low maintenance.
Key Features
Compact Table Top Design
Space-saving structure allows easy installation and convenient industrial operation.
High-Speed Marking
Produces clear, accurate, and permanent markings with excellent efficiency.
24/7 Service Support
Dedicated local and online support for uninterrupted machine performance.
Free Installation
Complete installation and operator training provided at client premises.
Technical Specification
| Model |
PULSE |
| Laser Type |
Fiber Laser |
| Laser Output Power |
20W / 30W / 50W / 70W / 100W |
| Marking Area |
50 × 50 mm, 100 × 100 mm, 170 × 170 mm |
| Marking Speed |
10000 mm/Second |
| Min. Character Size |
0.2 mm, 0.5 mm |
| Min. Line Width |
50 μm – 90 μm |
| Wavelength |
1064 nm |
| Beam Quality M2 |
< 1.6 |
| Power Stability (8h) |
< ±1% rms |
| Pulse Repetition Frequency |
1.6 kHz – 1000 kHz |
| Marking Depth |
≤ 0.016″ |
| Repetition Accuracy |
±0.0001″ |
| Power Consumption |
500W |
| Indication Light |
Red Light Wavelength = 650 nm |
| Running Temperature |
15℃ – 35℃ |
| Electrical Source Requirement |
110 – 220V / 50Hz (60Hz) / 4A |
| Dimensions (L × W × H) |
650 × 700 × 1600 mm |
| Weight |
125 Kg |
