Product Overview
The Fiber Laser Marking Machine is designed for high-speed and permanent marking on metal and industrial components.
Using advanced fiber laser technology, it delivers precise, clear, and durable markings with excellent efficiency and low maintenance.
Its compact design and reliable performance make it ideal for industrial manufacturing, branding, and product identification applications.
Key Features
Permanent High-Speed Marking
Produces sharp, accurate, and long-lasting markings with excellent speed and precision.
Low Maintenance Design
Reliable fiber laser technology ensures stable performance and reduced maintenance costs.
24/7 Service Support
Dedicated local and online support for smooth and uninterrupted machine operation.
Free Installation
Complete installation and operator training provided at client premises.
Technical Specification
| Model |
PULSE |
| Laser Type |
Fiber Laser |
| Laser Output Power |
20W / 30W / 50W / 70W / 100W |
| Marking Area |
50 × 50 mm, 100 × 100 mm, 170 × 170 mm |
| Marking Speed |
14000 mm/Second |
| Min. Character Size |
0.2 mm, 0.5 mm |
| Min. Line Width |
50 μm – 90 μm |
| Wavelength |
1064 nm |
| Beam Quality M2 |
< 1.6 |
| Power Stability (8h) |
< ±1% rms |
| Pulse Repetition Frequency |
1.6 kHz – 1000 kHz |
| Marking Depth |
≤ 0.016″ |
| Repetition Accuracy |
±0.0001″ |
| Power Consumption |
500W |
| Indication Light |
Red Light Wavelength = 650 nm |
| Cooling Mode |
Air Cooling |
| Running Temperature |
15℃ – 35℃ |
| Electrical Source Requirement |
110 – 220V / 50Hz (60Hz) / 4A |
| Dimensions (L × W × H) |
650 × 700 × 1600 mm |
| Weight |
135 KG |
